研华SKY-7632D 是一款第三代Intel®Xeon®可扩展处理器，通过分散核心布局平衡CPU和GPU性能，支持宽温支持，最高可达45，由Redfish管理的研华平台和安全的web界面
如需帮助,请联系我们
免费电话：400-880-8951
公司邮箱：advavee@outlook.com
咨询客服：一站式采购
批量采购定制咨询，请发送您的需求，我们将立即回复。
Specifications
| System P/N | SKY-7632LP / SKY-7632FH | |
|
Processor |
Family | 3rd Gen. Intel® Xeon® Scalable processors |
| Number | 2 | |
| Cores | up to 32 cores | |
| Cache | L3 Cache (1.5MB/core) | |
| Speed | up to 3.1 Ghz | |
| Max TDP | 205W | |
|
Memory |
Type | DDR4 ECC-REG 2666/2933/3200 MHz
RDIMM/LRDIMM, support Barlow Pass |
| 16 | ||
| Capacity | Up to 128GB per slot | |
|
Storage |
2.5" HDD/SSD | 6 (front) |
| 3.5" HDD | N/A | |
| M.2 SSD | 2 x NVMe | |
|
Expansion Slots |
[SKY-7632LP]
3 x Low profile PCIe4.0 x16 2 x Low profile PCIe4.0 x8 [SKY-7632FH] 2 x DW FH/FL PCIe 4.0 x16 |
|
|
I/O & Ports |
Network Interfaces | 2 x GbE RJ45 |
| USB | 5 x USB3.0 (front) | |
|
LED Indicator |
1 x HDD activity LED 1 x System Alarm LED
1 x LAN1, LAN2 activity LED |
|
| Video | 1 x VGA | |
| Others | 1 x Serial port (COM) 1 x RJ45 IPMI port | |
| Power Supplies | Type | CRPS |
| Power Rating | 800W red. AC PSU / (Optional) 1200W | |
| System Cooling | 4 system FAN with smart FAN control | |
|
Mechanical |
Form Factor | 2U |
| Dimensions (W x H x D) mm | 438 x 87 x 450 mm | |
| Weight (KG) | 25 kg | |
|
System Management |
Aspeed AST2600 BMC
Advanced Lights Out Management compliant to IPMI2.0 and Redfish with security and availability enhancements iKVM Support |
|
| Supported OS | Linux (CentOS, Red Hat, Ubuntu), Windows server | |
|
Environment |
Humidity Operational (non-condensing) | 5% to 85% |
| Operational Temperature | 0°C (32°F) to 45°C (113°F) | |
| Storage Temperature | -40 °C (-40 °F) to 70 °C (158 °F) | |
| Certification | CE/FCC/CB/UL | |
Ordering Information
| PN | CPU | PCH | Memory | PCIe slots | Storage | I/O | PSU |
|
SKY-7632LP-06A1R |
Dual socket, 3rd Gen. Intel® Xeon® Scalable processors |
Intel® C621A chipset |
16 RDIMM/ LRDIMM slot, up to 3200 MHz |
3 x Low profile PCIe 4.0 x16
2 x Low profile PCIe4.0 x8 |
6 x 2.5" HDD/SSD 2 x M.2 NVMe |
2 x 10/100/1000 RJ45
1 x RJ45 management port 5 x USB3.0 1 x VGA 1 x Serial power (COM) |
Redundant 1+1 CRPS 800W |
|
SKY-7632FH-06A1R |
Dual socket, 3rd Gen. Intel® Xeon® Scalable processors |
Intel® C621A chipset |
16 RDIMM/ LRDIMM slot, up to 3200 MHz |
2 x DW FH/FL PCIe 4.0 x 16 |
6 x 2.5" HDD/SSD 2 x M.2 NVMe |
2 x 10/100/1000 RJ45
1 x RJ45 management port 5 x USB3.0 1 x VGA 1 x Serial power (COM) |
Redundant 1+1 CRPS 800W |
Packing List
| Part no. | Description |
| 1970004567N001 | 2U CPU Heatsink |
| 1651003476-01 | LGA 4189 P4 CPU socket Carrier |
Optional Accessories
| Part no. | Description |
| 1702002600 | Power cord 3P 180 cm, USA |
| 1702002605 | Power cord 3P 180 cm, Europe |
| 1702031801 | Power cord 3P 180 cm, UK |
| 1700000237 | Power cord 3P 180 cm, JP |
| 1700009652 | Power cord 3P 180 cm, China |
| 1700027969-01 | Power cable for GPU card |
| 1970004565N001 | 1U CPU Heatsink |
| 968DE00078 | Short-depth full extension slide rail |
