| 系统P/N | SKY-7223DT-06A1R | SKY-7223DA-06A1R | |
| 处理器 | 系列 | 第二代 Intel® Xeon® Scalable 处理器(Cascade Lake) | |
| 数量 | 2 | ||
| 内核数 | 32 cores | ||
| 频率 | 2.20 GHz | ||
| 最大TDP | 165W | 105W | |
| 芯片组 | Intel C626 | ||
| 内存 | 技术 | DDR4 LRDIMM/RDIMM, 高达2933MHz | |
| 插槽 | 16 | ||
| 容量 | Maximum 2T ECC LRDIMM | ||
| Maximum 1T ECC RDIMM | |||
| 存储 | 2.5" HDD/SSD | 4*NVMe/SATAIII plus 2*SATAIII | 6*SATAIII |
| 3.5" HDD | NA | ||
| M.2 SSD | 2*NVME/SATAIII | ||
| 其他 | NA | ||
| 扩展槽 | Up to 4*FHFL + 2*FHHL | ||
| I/O 端口 | 网络接口 | 6*10G SFP+ plus 2*1G GbE | |
| USB | 2*USB3.0 | ||
| LED 指示灯 | PW LED, Status LED, ID LED | ||
| 视频 | 1*VGA | ||
| 其他 | 1*GbE management port, 1*console port | ||
| 时钟同步 | 1588v2, Cascading clock through RS422(1 pps + TOD), GPS （可选） | NA | |
| 电源 | 类型 | CRPS | |
| 功耗 | 1200W | 800W | |
| 散热系统 | 4*8038 风扇 | ||
| 物理特性 | 外形 | 2U | |
| 尺寸 (W x H x D) mm | 448 x 88 x 440 mm | ||
| 重量(KG) | 15kg | ||
| 系统管理 | 工业标准 BMC, IPMI v2.0 / Redfish compliant, with web interface and iKVM | ||
| 操作系统 | Linux (CentOS, Red Hat, Ubuntu), Windows server | ||
| 环境 | -5 ~ 45 °C (23 ~ 113 °F) | ||
| 认证 | CCC | ||
| 料号 | CPU | PCH | 内存 | 存储 | PCIe 插槽* | I/O | PSU | Others |
| SKY-7223DT-06A1R | 第二代Intel® Xeon®
Scalable 处理器 (Cascade Lake) Support up to 165W TDP/socket |
Intel C626
(w/QAT) |
16*DDR4 2933MHz
slots reserved. Support up to 16* DDR4 moudle |
Support up to
4* 2.5" NVMe/SATAIII plus 2* 2.5" SATAIII |
Default:
1*Riser CardA plus 1*RiserCardB Support up to: 2*130W PCIEX16 2*25W PCIEX8 |
6*10G SFP+
2*GbE 1*GbE MGM 1*Console Port 1*VGA 2*USB3.0 |
CRPS
1200W |
1* 时钟
同步模块 |
| SKY-7223DA-06A1R | 第二代. Intel® Xeon®
Scalable 处理器 (Cascade Lake) Support up to 105W TDP/socket |
Intel C626
(w/QAT) |
16*DDR4 2933MHz
slots reserved. Support up to 6* DDR4 moudle |
due to PSU SKU
Support up to 6* 2.5" SATAIII |
Default:
1*Riser CardA plus 1*Riser CardB Support up to: 2*75W PCIEX16 2*25W PCIEX8 |
6*10G SFP+
2*GbE 1*GbE MGM 1*Console Port 1*VGA 2*USB3.0 |
CRPS
800W |
NA |
注意:
Riser CardA (2*PCIeX16)
Riser CardB (1*PCIeX16, 2*PCIeX8)
Time Sync & GPS Module solution occupied 1*PCIe expansion space
| 料号 | 描述 |
| 1960081155N001 | CPU Heatsink |
| 1651003167-01 | CPU Clip for Heatsink |
| 968DE00025 | Slide Rail |
| 1700020691-01 | Console Cable |
| 料号 | 描述 |
| 1702002600 | 3P 电缆线 180 cm, USA |
| 1702002605 | 3P 电缆线 180 cm, Europe |
| 1702031801 | 3P 电缆线 180 cm, UK |
| 1700000237 | 3P 电缆线 180 cm, JP |
| 1700009652 | 3P 电缆线 180 cm, China |
| 1700027969-01 | GPU卡电源线 |
| 96PSR-A800WCRP | AC 800W PSU CRPS Module |
| 96PSRM-A1K2WCRPA | AC 1200W PSU CRPS Module |
| 968DE00025 | Slide Rail |
| 98923260J0E | TPM2.0 Module |
| 1700020691-01 | Console Cable |
