SKY-712V4

基于 Intel® Xeon® 6 处理器的 1U 高性能服务器，用于 AI 推理、高频交易和实时数据分析。

1U 31″ 深机架式服务器
双路 Intel® Xeon® 6 处理器
DC-MHS M-FLW 主板
32 个 DDR5 DIMM 插槽（每个 CPU 16 个 DIMM），最大容量可达 4TB，速度最高可达 6400MHz（1DPC）/5200（2DPC）
2 x PCIe Gen5 x16（全高 | 3/4 长）
1 x OCP3.0 Gen5 x16
16 个 E3.S /12 个 U.2 NVMe 硬盘
2 个 NVMe 2280 M.2 硬盘
符合 IPMI 2.0 的管理，具备可靠性和安全性增强
438.0 x 770.0 x 43.2 mm (17.2″ x 30.3″ x 1.7″)

SKY-712V4 _ 技术规格

分类： 5G 和边缘运算服务器, 云、网络和服务器, 单节点服务器标签： SKY-712V4

如需帮助,请联系我们

免费电话：400- 880- 8951

邮箱：advavee@outlook.com
咨询客服：一站式采购

批量采购定制咨询，请发送您的需求，我们将立即回复。

产品资讯

Specifications

Processor System	CPU	Two Intel® Xeon® 6 processors , CPU TDP up to 250W
Memory	Technology	DDR5 DIMM slot, supports registered ECC DDR5 DIMM only
	Max Capacity	Max memory up to 2TB 6400MHz(1DPC)/4TB 5200 MHz(2DPC)
	Socket	32 x 288-pin DIMM
PCIe	Expansion slot	2 x PCIe Gen5 x16 (FH\|3/4L) 1 x OCP3.0 Gen5 x16
IO and LEDs	Front IO and LEDs	USB3.2 Gen1; Power button/LED; ID button/LED; Reset button; Status LED*
IO and LEDs	Rear IO	ID button/LED; VGA; 2x USB3.2 Gen 1; RS-45 Console; Software definable button
Ethernet	Management Interface	NC-SI (BMC to I210-AT)
	LAN	2 x RJ45 1 GbE/2 x 10Gbase-T
	LAN Controller	1 GbE: Intel i210-AT/10 GBase-T: Intel X710-AT2
Storage	16 x E3.S or 12 x U.2 NVMe drive 2 x NVMe 2280 M.2 drive
Power Supply	Input	1600W 1+1 platinum redundant power supply with PMBus
Environment	Humidity Operational (non-condensing)	95%@40 °C
	Operation Temperature	0 °C (32 °F) to 35 °C (95 °F)
	Storage Temperature	-40 °C (-40 °F) to 70 °C (158 °F)
Cooling	Chassis Fan	8x 4056 fan with SmartFan control
	Thermal Control	Three separate thermal zones for motherboard and PCIe cards
	Redundancy	Resilient to single fan failure
System Management	IPMI2.0 and Redfish API	Aspeed AST2600 BMC with Advantech System Management Solution Advanced Lights Out Management compliant to IPMI2.0 with security and availability enhancements iKVM Support Advantech Web GUI style Node Manager Configurable shared or dedicated NIC support Optional TPM 2.0 Optional Secure Boot Chassis Intrusion Protection Cryptographically signed BMC firmware, optional signed BIOS firmware NIST.SP.800-193 Sustainable, see https://campaign.advantech.online/en/Cloud-IoT/software/pop_EnhancedSecurity. html
Physical	Dimensions (W x D x H)	438.0 x 770.0 x 43.2 mm (17.2" x 30.3" x 1.7")
Physical	Weight	20kg

Ordering Information

Part Number

Description

SKY-712V4-316R0000

31" 2-socket 1U Server Intel® 6 Processor, 16 x E3.S NVMe drive, 2 x PCIe G5 x16 FH3/4L slot, 1 x OCP3.0 slot, AC 1600W 1+1 Power Supply

SKY-712V4-N12R0000

31" 2-socket 1U Server Intel® 6 Processor, 12 x U.2 NVMe drive, 2 x PCIe G5 x16 FH3/4L slot, 1 x OCP3.0 slot, AC 1600W 1+1 Power Supply

Optional Accessories

Part Number	Description
1700027909-02	Power cable 3P 183 cm, USA
1702002605	Power cable 3P 180 cm, Europe
1700000237	Power cable 3P 180 cm, JP
1700009652	Power cord 3P 180 cm, China
968DE00079	1U SKY-7 slide rail
