NMC-2503

研华 NMC-2503 是一款4端口25GbE SFP28网络夹层卡，支持1 x英特尔®E810-CAM1，符合CE、FCC和RoHS标准

如需帮助,请联系我们

免费电话：400-880-8951

公司邮箱：advavee@outlook.com
咨询客服：一站式采购

批量采购定制咨询，请发送您的需求，我们将立即回复。

Specifications

Controller	1 x Intel E810-CAM1
Interface	1 x PCIe x8, Gen4
Speed	25GbE
Port	4 x SFP28 Ports
LAN LED definition	Link/Act LED/Bypass LED: Link: Green on Activity: Green Blanking LAN Bypass: NA Disconnect: NA
Advanced Software Features	Teaming support IEEE 802.3ad IEEE 802.1Q VLANs IEEE 802.3 2005 flow control support Interrupt moderation
OS Support	Linux (CentOS, Red Hat, Ubuntu), Windows server
Operating Conditions	Operation: 0 ~ 40°C Storage: -40 ~ 70°C
Power Voltage & consumption	+12V ± 10% 15W
Dimension (W x H x D)	74.6 x 42.4 x 174.7 mm
Compliance	CE/FCC, RoHS

Ordering Information

Type	Part Number	Description
NMC	NMC-2503FN-04A1	4 Ports 25GbE SFP28 Thumbscrew Type
Transceiver	NMC-TEL025S-00A1	25Gbps SR 850nm 70m/100m
Transceiver	NMC-TEL025L-00A1	25Gbps LR 1310nm 10km
