| CompactPCI Connector | J3/J4/J5 | ||
| Power | Power consumption | +3.3V
3.5A |
+5V
1A |
|
Environment |
Operating | Non-Operating | |
| Temperature | 0 ~ 60° C (32 ~ 140° F) | -40 ~ 85° C (-40 ~ 185° F) | |
| Humidity | 95% @ 40° C, non-condensing | 95% @ 60° C, non-condensing | |
| Physical Characteristics | Dimensions (WxD) | 233.35 x 80 mm (9.2" x 1.5"), 1-slot width | |
| Weight | 0.3 kg (0.66 lbs) | ||
|
Part Number |
Rear Panel | On-board Header / Socket / Connector | ||||||||||
| USB2.0 | LAN (RJ45)* | COM (RJ45)** | DP | DVI-D | USB2.0 | COM (RS232/422/485) | M.2 B-key SATA (2242 Type) | Slot Width | Audio | GPIO | Conn. | |
| MIC-360-R1S1 | 3 | 4 | 2 | 1 | 1 | 3 | 2 | 2 | 1 | 1 | 8-bit | J3,J4,J5 |
Note:*LAN1 & LAN2 can meet PICMG 2.16 R1.0 specification
**COM ports on the front panel supports RS232/422/485.
| Rear I/O Board | CPU Board |
| MIC-360-R | MIC-360 series |
