硬盘位 |
External | Internal | |
| 5.25" | - | 0 | |
| 3.5" | - | 1 | |
| 2.5" | - | 2 | |
| 散热 | 风扇 | 1 (12cm/85CFM) + 1 Optional(12cm/85CFM) | |
| 空气滤网 | Yes | ||
| 其他 | LED指示灯 | Power status and HDD activity | |
| 控制 | Power switch and system reset button | ||
|
工作环境 |
Operating | Non-Operating | |
| 工作温度 | 0 ~ 40 °C (32 ~ 104 °F) | -40 ~ 70 °C (-40 ~ 158 °F) | |
| 工作湿度 | 95% @ 40 °C, 非冷凝 | 95% @ 60 °C, non-condensing | |
| 振动（5 ~ 500 Hz） | Random 1Grms | Sine 2G | |
| 冲击 | 10 G (with 11 ms duration, half sine wave) | ||
| 物理特性 | 尺寸（宽× 高× 深） | 320 x 180 x 321 mm 12.6" x 7.1" x 12.6") | |
| 重量 | 6.99 kg (15.41 lb) |
| 料号 | 电源 | 功率 | 80 Plus |
| IPC-720-70AEA1 | PS8-700ATX-BB | 700W | Bronze |
| IPC-720-50AEA1 | PS8-500ATX-BB | 500W | Bronze |
| IPC-720-30DEA1 | PS8-300ATX-ZBE | 300W | Bronze |
| IPC-720-00XEA1 | - | - | - |
| 料号 | 描述 | 数量 | |
|
Optional 2nd System fan |
1751000748-01 | Fan Axial 120x120x26 3000RPM 85CFM | 1 |
| 1700030260-01 | System fan cable | 1 | |
| 1962860100 | FAN Guard 12*12cm | 1 | |
| 1939251000 | Screw T5x10L S/S D=6.3 H=1.2 (2+) ST Ni | 8 | |
| PSU Bracket for 150mm-depth PSU | 1960120585N010 | IPC-720 PSU bracket, for 150mm-depth 850W PSU PS8-850ATX-GZ | 1 |
|
Expansion Card Hold-down Bracket (4pcs hold down brackets are included in each IPC-720) |
1960120584N000 | Hold-down bracket for IPC-720 | 1 |
| 199002K000 | Rubber Spacer 14*14*2mm | 1 | |
| 1930007122-01 | Thumb Screw M4*5L SP/S D=9.0 H=6.5 (+-) ST WZn | 1 | |
| GPU Tail-End Retainer | 1960100024N110 | GPU Retainer for Dual-Fan RTX 5060, RTX 5070 | 1 |
| (For Dual-Fan RTX 5060, RTX 5070) | 1933030500 | Screw M3x5L 1/4R/S D=6.9 H=1.9 (2+) ST Ni | 4 |
| SSD Bracket | 989K008734 | Module to fix two 2.5" HDDs in 3.5" bay | 1 |
| 料号 | 描述 | 数量 |
| 2130025704N000 | System fan filter | 1 |
| 1960005359T00A | Mounting Bracket | 2 |
