| Drive Bay | External Internal | |
| 3.5" | 2 SATA3/SAS3 | |
| 2.5" | Optional 2 SATA or NVMe HDD Tray (occupied 1 3.5" HDD space) | |
| Cooling | Fan | 2 x 12cm front fans |
| Air Filter | Yes, on the front removable bezel. | |
| Front I/O Interface | USB3.0 | 2 |
| USB3.2 | Type-C Gen2 x2 | |
| Miscellaneous | LED Indicators | LAN1, LAN2, HDD, Power, Information |
| Environment | Operating Non-Operating | |
| Temperature | 0 ~ 40 °C -40 ~ 70 °C | |
| Humidity | 10 ~ 95% @ 50 °C, non-condensing 10 ~ 95% @ 60 °C, non-condensing | |
| Vibration(5-500Hz) | 0.3Grms | |
| Shock | 3G (with 11ms duration, half sine wave) | |
| Physical Characteristics | Dimension (W x H x D) | 340 x 195 x 430 mm (13.4" x 7.7" x 16.9") |
| Weight | 5.8 kgs | |
| Part Number | Description |
| HPC-5422-85ZX | With 850W single PSU |
| HPC-5422-12ZX | With 1200W single PSU |
| Part Number | Description | Quantity |
| Wallmount Bracket | 2 | |
| GPU Retainer HPC-5422 | 2 |
| Part Number | Description | Quantity |
| Module to support Dual 2.5" Hot-swappable SATA/SAS HDDs with HDD Trays | 1 | |
| Module to support Dual 2.5" Hot-swappable NMVe HDDs with HDD Trays | 1 | |
| 1700036195-01 | M cable Slim SAS 38P/SATA 7Px4+2x5P-2.54 60cm (for ASMB-818/…) | 1 |
| A cable MCIO 38P(M)/MCIO 38P(M) 60cm (for ASMB-561) | 1 | |
| 1700035750-01 | A cable MCIO 74P(M)/MCIO 38P(M)x2 60cm (for ASMB-981/…/Tri-mode RAID Card) | 1 |
