| Form Factor | Micro ATX form factor | |
| Processor System | Socket | Intel® LGA 1851 |
| CPU type | InteI® Core™ Ultra 9/7/5 processors (TDP up to 125W) | |
| Core Logic | Chipset | Intel® W880 chipset |
|
Memory |
Total slots | 4 (Dual Channel) |
| Capacity | Maximum 192 GB | |
| Memory type | DDR5 ECC/Non-ECC 5600*/4800/4400 MT/s UDIMM (288-pin) | |
| Memory size | 8 GB, 16 GB, 32 GB , 48 GB | |
|
Expansion Slots |
Total PCIe slots | 4 |
| Slot location 1 | - | |
| Slot location 2 | - | |
| Slot location 3 | - | |
| Slot location 4 | PCIe x4 slot (Gen 4 x4 link) | |
| Slot location 5 | PCIe x4 slot (Gen 4 x4 link) | |
| Slot location 6 | PCIe x16 slot (Gen 5 x16 link) | |
| Slot location 7 | PCIe x4 slot (Gen 5 x4 link) | |
| Graphics | Controller | Intel® HD Graphics |
| VRAM | 1 GB maximum shared memory with 2 GB and above system memory installed | |
|
Storage |
SATA controller | Intel® W880: 5 SATA3 6Gb/s ports with Rapid Storage Technology support (for Windows only) (Supports software RAID 0, 1, 10 & 5) |
| SAS controller | - | |
| Networking | GbE LAN | 1 x Intel® I219LM + 2 x Intel® I226 + 1 x Intel® I210AT |
|
Onboard I/O Connector |
LPT connector | - |
| PSU connector | 24-pin SSI power connector + 8-pin SSI 12 V power connector | |
| USB connector | 9 (2 x USB 3.2 Gen1, 4 x USB 2.0, 1 x USB 2.0 Type-A, 1 x USB3.2 Type-A, 1 x USB 3.2 Gen2 Type-C) | |
| M.2 connector | 1 x M.2 2280 (PCIe G4 x4 link) | |
| Fan header | 5 x (4-pin) | |
| SMBus | 1 | |
| Chassis intrusion | 1 | |
| Front LAN LED | 2 | |
| Serial port header | 4 (2 x RS-232 dual-port (2 ports)) | |
| Audio Header | 1 x (ALC 888S) | |
| PS/2 KB/Mouse | 1 x (Optional PS/2 KB/Mouse cable and bracket required) | |
|
Rear I/O Connector |
External serial port | 1 (via COM cable in the package) |
| External USB port | 4 x (USB 3.2 Gen 2) | |
| VGA port | 1 x (Resolution up to 1920 x 1200 @ 60 Hz) | |
| HDMI | 1 x (Resolution up to 4096 x 2160 @ 60 Hz) | |
| Display Port | 2 x (Resolution up DP* with DSC to 8K60 Hz 30bpp) | |
| RJ-45 | 4 | |
| PS/2 KB/mouse | - | |
| Audio | 2 x (Mic-in , Line-out) | |
|
Power Requirement |
Power On | 3.3 V 5 V 12 V 12V_8P 5 VSB |
| (Ultra5 245K 4.2GHz DDR5 5600 16 GB x 4) | 1.56 A 1.91 A 0.36 A 0.33 A 0.63 A | |
|
Environment |
Operating Non-operating | |
| Temperature | 0 ~ 60 °C, depends on CPU speed and cooler solution -40 ~ 85 °C | |
| Humidity | 40 °C @ 95% RH Non-condensing 60 °C @ 95% RH Non-condensing | |
| Watchdog Timer | Output | System reset |
| Interval | Programmable 1 ~ 255 sec/min | |
| Physical Characteristics | Dimensions | 244 x 244 mm (9.6 x 9.6 in) |
* 5600MT/s can only be supported with 1 DIMM per channel configuration (2 DIMMs in total).
| Part Number | Chipset | Memory | Display | LAN | SATAIII | IPMI |
| ASMB-589G2-00A1 | W880 | DDR5 ECC/Non-ECC UDIMM | VGA + HDMI + DPx2 | 2 | 5 | Optional |
| ASMB-589G4-00A1 | W880 | DDR5 ECC/Non-ECC UDIMM | VGA + HDMI + DPx2 | 4 | 5 | Optional |
| ASMB-589G4-00A1U | W880 | DDR5 ECC/Non-ECC UDIMM | VGA + HDMI + DPx2 | 4 | 5 | Optional |
| Part Number | Description | Quantity |
| 2042058800 | Startup manual | x 1 |
| 1700003194 | SATA data cables | x 2 |
| 1700022749-11 | SATA power cables | x 2 |
| 1700001788 | COM1 cable | x 1 |
| 1960118666T001 | I/O shield (for 2U chassis or higher) | x 1 |
| 1930005673-11 | Screw for M.2 device | x 1 |
| Part Number | Description |
| 1970005958N001 | LGA 1700 CPU Cooler for 3U/4U Tower Cooler (CPU 230W at ambient 30°C) |
| 1970005531T001 | LGA 1700 CPU heatsink for 1U chassis |
| 1970005436T001 | LGA 1700 CPU cooler for 2U/4U chassis (CPU 125W) |
| 1970005349T000 | LGA 1700 CPU cooler for 2U/4U chassis (CPU under 65W) |
| 1960120024N001 | 1U I/O shield for ASMB-589 |
| 1700031926-11 | JFP1 cable for 1U chassis |
| 1990040376T000 | 1U air duct for ASMB-588 + HPC-7120S |
| 1700002204 | Dual-port USB 2.0 cable (27 cm / 10.6 in) with bracket |
| 1700008461 | Four-port USB 2.0 cable (30.5 cm / 12 in) with bracket |
| 1700028292-01 | Dual-port USB 3.0 cable (30 cm / 11.8 in) with bracket |
| 1701090401 | Single port RS-232 COM cable (40 cm / 15.7 in) with bracket |
| 1700026254-01 | Dual-port RS-232 COM cable (45 cm/ 17.7 in) with bracket |
| 1700036239-01 | M cable USB-E 20P(M)/USB-C 24P(F) 65cm W/BKT 3.2 |
| PCA-TPMSPI-00A1 | TPM 2.0 Module by SPI |
Note: Users need to purchase the ASMB-589 proprietary CPU cooler from Advantech. Other brands of CPU coolers may NOT be compatible with ASMB-588.
