| System P/N | FWA-3080R-00A1RU | FWA-3080H-00A1SU | |
| Form Factor | 1U | ||
|
Processor System |
Processor | AMD Ryzen™ Embedded 7000 / EPYC™ 4005, Max. up to 65W | |
| Core Count | 16 | ||
| Base Frequency | 3.8GHz | ||
| Chipset | B650 | ||
| BIOS | AMI UEFI | ||
| Virtualization | |||
|
Memory |
Technology | DDR5, up to 5600 MT/s | |
| Max. Capacity | 128GB (32GB per slot) | ||
| Socket | 4 x 288-Pin DIMM | ||
| ECC Support | Yes (ECC / Non-ECC) | ||
|
Networking |
Controller | 2 x I350-AM4
2 x I210-AT |
|
| 1GbE | 8 x 1GbE RJ45 (4 x 1GbE SFP by project base) | ||
| LAN Bypass | Two pairs LAN Bypass | ||
| Expansion Slot | PCIe x8 | 1 (Gen 4, FH/HL) | |
| NMC | 2 (PCIe Gen4 x 8) | ||
| IPMI | IPMI 2.0 and Redfish compliant
2 x shared 1GbE MGMT LAN for IPMI port |
N/A
2 x 1GbE MGMT LAN Port |
|
| Storage | 2.5" Bay | 2 x SATA HDD/SATA SSD | |
| M.2 2 x 2280 M.2 M-key slot for SATA SSD | |||
|
I/O |
Console | 1 x RJ45 type console | |
| USB | 2 x USB 3.2 Gen2 ports | ||
|
LED Indicator |
1 x SW-defined LED (Amber/Green) 1 x Alert LED by IPMI (Amber)
1 x HDD LED (Green) 1 x Power (Green) |
||
| Display | 1 x VGA port | ||
| Button | 1 x Power button
1 x SW-defined button |
||
| TPM | Support by TPM 2.0 module (Optional) | ||
|
Power Supply |
Power Type | AC Redundant | AC Single |
| Watts | 300W | 300W | |
| Input | 100-240 V | ||
| Connector | AC 3pin plug | AC 3pin plug | |
|
Environment |
Operating Temperature | 0 ~ 40 °C (32 ~ 104 °F) | |
| Non-operating Temperature | -40 ~ 70 °C (-40 ~ 158 °F), 60 °C@95% Non-Condensing Humidity | ||
| Vibration Resistance (Operation) | 5-500 Hz, 0.3 Grms, 3 axes, 1 hr/per axis | ||
| Shock Protection (Operation) | 10 G, 11 ms | ||
| Cooling | 5 x System fans with smart fan feature | ||
|
Mechanical |
Construction | SGCC |
| Mounting | Rackmount | |
| Dimensions (W x H x D) | 438 x 43.7 x 421.20 mm (17.24" x 1.72" x 16.58") | |
| Weight | 6.53 kg (14.39 lb) G.W. | |
| OS Support | Linux (Ubuntu) | |
|
Advantech S/W Packages |
ALBPCU
ipmitool Server iManager (Linux base) - Network device identifier (NDI) |
|
| Certification | EMC/Safety | CE, FCC, CB, UL, CCC |
| Part Number | Processor | DDR5 | PCH | NMC
Slot |
PCIe
Slot |
Storage Bay | USB3.0 | IPMI | MGMT
Port |
Console Port | LAN Port | System Fan | PSU |
| 1G RJ45 | |||||||||||||
| FWA-3080R-00A1RU | AMD Ryzen™ Embedded 7000 / EPYC 4005 | 4 | B650 | 2 | 1 | 2 | 2 | YES | 2 | 1 | 8 | 5 | 2 |
| FWA-3080H-00A1SU | AMD Ryzen™ Embedded 7000 / EPYC 4005 | 4 | B650 | 2 | 1 | 2 | 2 | N/A | 2 | 1 | 8 | 5 | 1 |
| Part Number | Description | Quantity |
| 1700020691-01 | Console cable D-SUB 9P(F)/RJ45 220cm | 1 |
| 1960086225T004 | Rack mount brackets | 2 |
| 1700034038-01/
1700020513-21 |
SATA cable kits | 2 |
| 1970006374N001 | CPU heatsink | 1 |
| Part Number | Description |
| 1702002600 | Power cord 3P 180 cm, USA |
| 1702002605 | Power cord 3P 180 cm, Europe |
| 1702031801 | Power cord 3P 180 cm, UK |
| 1700000237 | Power cord 3P 180 cm, JP |
| 1700009652 | Power cord 3P 180 cm, China |
| 968DE00026 | Slide rail_USH-40SVH635-AD1_Martas |
| FWA-3050-800WPSU | 800W DC Power kit |
| 1700027334-01 | USB for RJ45 console cable, 190cm |
| PCA-TPMSPI-00A1 | TPM 2.0 Module by SPI for CPU cards, A101-1 |
