| Controller | Intel E830-CCAM1 |
| Interface | PCIex8, Gen 5 |
| Speed | 100GbE or 200GbE |
| I/O Port | 2 x 100G QSFP28 ports or 1 x 200G QSFP56 port |
| Data Rate | 2 x 100G or 1 x 200G |
| Transceiver types | LR4, SR4, AOC, DAC |
| NMC Type | Thumbscrews |
| LAN LED definition | Link: Green on
Activity: Green Blanking |
|
Advanced Software Features |
Support:
IEEE 802.1Q, 802.1P VLAN tags and priority IEEE 802.1Qaz (ETS) IEEE 802.1Qbb (PFC) IEEE 1588v2 |
| OS support | Linux (CentOS, Red Hat, Ubuntu), Windows server |
| Operating Temperature (Air flow 0.7 m/sec) | 0°C ~ 40°C (23°F~113°F) with system |
| Storage Temperature | -20°C ~ 65°C (-4°F~149°F) |
| Storage Humidity | 5 ~ 85 % @ 60 °C (140 °F) |
| Dimension (W x H x D) | 74.3 x 42.2 x 174.7 mm |
| Weight | 0.5 kg |
| Certification | CE/FCC, RoHS |
| Part Number | Description |
| NMC-6005FN-02A1 | 2port 100G QSFP28+ E830 |
| NMC-6005FN-01A1 | 1port 200G QSF56+ E830 |
