| 控制器 | 2 x Intel i350-AM4 |
| 接口 | 1 x PCIe x4, Gen2 |
| 数据速率 | 1GbE |
| 端口 | 8 x RJ45 |
| LAN Bypass | 4 pairs Advanced LAN Bypass (optional) |
|
LAN LED definition |
Speed LED(Left on RJ45): 10Mbps:N/A
100Mps:Amber on (Downgrade speed) 1000Mbps:Green on (Maximum speed)
Link/Act/Bypass LED (Right on RJ45): Link: Green on Active: Green Blinking LAN Bypass: Amber on Disconnect: Amber blinking |
|
应用软件特性 |
合作支持：
IEEE 802.3ad IEEE 802.1Q VLANs IEEE 802.3 2005 flow control support Interrupt moderation |
|
支持OS |
Windows® Server 2012 R2, 2012, 2008 R2 X86-64 Linux RedHat EL 6.5 and 7.0 IA-32, X86-64, and IA-64
Linux SuSE SLES 11 SP3 and 12 IA-32, X86-64, and IA-64 FreeBSD 9 and 10 IA-32, X86-64, and IA-64 UEFI 2.1 and 2.3 X86-64 and I-64 VMware ESXi5.1, ESXi5.5 and ESXi6.0 X86-64 |
| 工作温度 | Operation: 0 ~ 45 °C
Storage: -20 ~ 60 °C |
| 电源电压 &
功耗 |
+12V ±10% 10W |
| 尺寸
(W x H x D) |
74.6 x 42.5 x 174.6 mm |
| 认证 | CE/FCC |
| 料号 | 类型 | 说明 |
| NMC-0807-08CBSB1 | Thumbscrew | 8 Ports 1GbE RJ45 |
