Drive Bay |
External | Internal | |
| 3.5” | 4 SATA3/SAS3
(2nd 4 SATA3/SAS3 optional) |
- | |
| 2.5” | - | 1 | |
|
Cooling |
Fan | 2 x 8cm +1 x 12cm
1*12cm system fan in rear window (optional) |
|
|
Liquid Cooling module |
Single Processor | Dual Processor | |
| CPU Socket | Intel LGA 4677 / 4710, AMD LGA6096 | Intel LGA 4677 / 4710 | |
| Fan Quantity | 3 x 12cm | 3 x 14cm | |
| Front I/O Interface | USB3.0 | 2 | |
| USB3.2 | Type-C Gen2 x2 | ||
| Miscellaneous | LED Indicators | LAN1, LAN2, HDD, Power, Information | |
|
Environment |
Operating | Non-Operating | |
| Temperature | 0~40oC | -40 ~ 70oC | |
| Humidity | 95% @ 40oC, non-condensing | 95% @ 70oC, non-condensing | |
| Vibration(5-500Hz) | 1Grms | 2Grms | |
| Shock | 10G (with 11ms duration, half sine wave) | ||
| Physical Characteristics | Dimension (WxHxD) | 240mm x 550mm x 620mm (9.45” x21.65” x24 | .41”) |
| Weight | 28kgs with Liquid Cooling Module | ||
-Chassis SKU
| Part Number | MB Form factor | CPU | GPU | Built-in PSU |
| HPC-7046-13ZX | ATX | Single | Up to 2*300W | PS/2 ATX3.1 1350W |
| HPC-7046-16ZX | ATX | Single | Up to 3*300W or 2*600W | PS/2 ATX3.1 1650W |
| E-ATX | Dual | Up to 2*300W or 1*600W | ||
Liquid Cooling Module SKU
| Part Number | Liquid Cooling Module | Available Motherboard |
| 1970006249N000 | Single Intel LGA4677/4710 | ASMB-807 / ASMB-817 / ASMB-808 / ASMB-818 |
| 1970006384N001 | Single AMD LGA6096 | ASMB-831 / ASMB-832 |
| 1970006380N001 | Dual Intel LGA4677/4710 | ASMB927 / ASMB-928 |
| Part Number | Description | Quantity | Remark |
| Fan Extension Cable | 3 | ||
| Fan Y-Cable | 1 | ||
| GPU Retainer HPC-7046_Short-depth | 2 | For D10.5” GPU Card |
| Part Number | Description | Remark |
| HPC-7046 2nd 4x3.5” HDD Kit | ||
| GPU Card Support Bracket Kit | For single slot GPU Card | |
| RPSU CRPS A/D 100-240V 1200W set (module*2+PDB) | ||
| GPU Retainer HPC-7046_Long-depth | For D13” GPU Card |
