SKY-8136S

1U 高性能边缘服务器搭载Intel® Xeon® 6 处理器

支持单路 Intel Xeon 6处理器
支持高达 8 x DDR5 6400 RDIMMs
支持 2 x FHFL PCIe 5.0 x16 slots, and 1x FHHL PCIe 5.0 x16 + 1x LP PCIe 5.0 x8 slots
支持最多 4x 热交换 SFF NVMe (PCIe Gen5 x4) SSDs
支持 2x 板载10GbE 端口

SKY-8136S _ 技术规格

如需帮助,请联系我们

免费电话：400- 880- 8951

邮箱：advavee@outlook.com
咨询客服：一站式采购

批量采购定制咨询，请发送您的需求，我们将立即回复。

Specifications

System model	SKY-8136S
Processor	Family	Intel® Xeon® 6 processors
	Number	1
	Cores	Up to 48 cores per socket
	Cache	L3 Cache (up to 288MB/CPU)
	Speed	Up to 4GHz
	Max TDP	250W
Memory	Type	DDR5 6400MHz RDIMM
	Slots	8
	Capacity	Up to 128GB RDIMM/slot Total Up to 1TB
Storage	2.5" HDD/SSD	Up to 4 x hot-swap SFF NVMe (PCIe Gen5 x4) SSDs
Storage	M.2 SSD	Up to 2 (M.2 2280 NVMe SSDs)
Expansion Slots	2 x FHFL PCIe 5.0 x16 slots , and 1x FHHL PCIe 5.0 x16 + 1x LP PCIe 5.0 x8 slots
I/O & Ports	Network Interfaces	2 x 10GbE RJ-45
	USB	Front: 1 x USB3.2 Gen1 Rear: 2 x USB 3.2 Gen1
	LED Indicator	1 Power status 1 System status 1 HD activity 1 Network activity 1 System UID
	Video	D-Sub (Front)
	Others	1 Serial console port (RJ-45)
Power Supplies	Type	1+1 red. AC (SlimType PSUs 800W (220 mm L))
Power Supplies	Power Rating	800W red. AC PSU
System Cooling	5 x modules (vertical access , hotswappable and N+1 redundant)
Mechanical	Form Factor	1U
	Dimensions (W x H x D) mm	438 x 43.5 x 568.1 mm (17.2" x 1.71" x 22.37")
	Weight (kg)	15 kg
System Management	AST2600 BMC with iKVM, WebUI and Redfish support
Supported OS	Linux (CentOS, Red Hat, Ubuntu), Windows server
Environment	Humidity Operational (non-condensing)	5% to 95%
	Operational Temperature	0 ~ 40°C (32 ~ 104°F)
	Storage Temperature	-40 ~ 70°C (-40~158°F)
Certification	CE/FCC/CB/UL
