| System P/N | SKY-641E3 | |
| Processor | Family | AMD EPYC 9004/9005 family processors |
| Number | 2 | |
| Cores | Up to 160 cores per socket | |
| Cache | L3 Cache (up to 256M/CPU) | |
| Speed | Up to 4.1GHz | |
| Max TDP | 400W | |
| Memory | Type | DDR5 5600MHz RDIMM |
| Slots | 24 | |
| Capacity | Up to 128GB RDIMM/slot Total Up to 3TB | |
| Storage | 2.5" (Hot Swap) | 8 (U.2 NvME) |
| M.2 2280 | 2 (NVMe) | |
| Expansion Slots | 10 FHFL PCIe 4.0 x 16 (up to 4 double width GPU, max 350W/ea TDP) 2 FHHL PCIe 5.0 x 8
1 OCP 3.0 PCIe x 16 slot |
|
| I/O & Ports | Network Interfaces | 2 GbE RJ45 (1 GbE RJ-45 Mgmt Share NIC)
2 10GbE RJ45 |
| USB | Front: 1 USB3.0, 1 USB2.0
Rear: 2 USB3.0 |
|
|
LED Indicator |
1 Power status
1 System status 1 HD activity 1 Network activity 1 System UID |
|
| Video | 1 D-sub (Front), 1 D-sub (Rear) | |
| Others | 1 Serial console port (RJ-45) | |
| Power Supplies | Type | CRPS 1+1 Redundancy |
| Power Rating | 2700W red. AC PSU | |
| System Cooling | 8 System Fans with Smart Fan Control | |
|
Mechanical |
Form Factor | 4U |
| Dimensions (W x H x D) mm | 438 x 88 x 650 mm | |
| Weight (KG) | 30 kg | |
| System Management | Aspeed AST2600
Advanced Lights Out Management compliant to IPMI2.0 and Redfish with security and availability enhancements iKVM Support Configurable shared or dedicated NIC support |
|
| Supported OS | Linux (CentOS, Red Hat, Ubuntu), Windows server | |
|
Environment |
Humidity Operational (non-condensing) | 5% to 85% |
| Operational Temperature | 0 °C (32 °F) to 35 °C (104 °F) | |
| Storage Temperature | -40 °C (-40 °F) to 70 °C (158 °F) | |
| Certification | CE/FCC/CB/UL | |
| Part Number | CPU | Memory | Storage | PCIe Slots | PSU |
|
SKY-641E3-N08R27A1 |
Dual socket, AMD EPYC 9004/ 9005 family processors (CPU TDP up to 400W) | 24x DIMM slots
DDR5 6400Mhz RDIMM/ MRDIMM |
8x U.2 NVMe SSD
2x M.2 2280 NvMe SSD |
10x FHFL PCIe 4.0 x 16
2x FHFL PCIe 5.0 x 8 1x OCP3.0 PCIe 5.0 x16 |
Redundant 1+1 CRPS 2700W |
| Part no. | Description | Qty |
| 1970005850T001 | AMD EPYC SP5 CPU heatsink | 2 |
| Part no. | Description |
| 1700021723-02 | UL Power Cord (125V,15A) |
| 1700033943-01 | BSMI Power Cord (125V,15A) |
| 1700023533-01 | EU Power Cord (250V,10A) |
| 1700023534-01 | UK Power cord |
| 1700035523-01 | GPU power cable with 12VHPWR connector |
| 9680017375 | Rail |
| 1970005835T001 | AMD EPYC SP5 heatsink for 400W CPU |
