Specifications
| Controller | 1 x Intel E810-CAM1 or E810-CAM2 |
| Interface | 1 x PCIe x8, Gen4 |
| Speed | 100GbE |
| Port | 1 or 2 x QSFP28 Ports |
|
LAN LED definition |
Link/Act LED/Bypass LED: Link: Green on Activity: Green Blanking LAN Bypass: NA Disconnect: NA |
|
Advanced Software Features |
Teaming support IEEE 802.3ad
IEEE 802.1Q VLANs IEEE 802.3 2005 flow control support Interrupt moderation |
| OS Support | Linux (CentOS, Red Hat, Ubuntu), Windows server |
| Operating Conditions | Operation: 0 ~ 40°C Storage: -40 ~ 70°C |
| Power Voltage & consumption | +12V ± 10% 15W |
| Dimension (W x H x D) | 74.6 x 42.4 x 174.7 mm |
| Compliance | CE/FCC, RoHS |
Ordering Information
| Type | Part Number | Description |
| NMC | NMC-6003L-01FSA1 | 1 Port 100GbE QSFP28 Thumbscrew Type |
| NMC | NMC-6003L-02FSA1 | 2 Ports 100GbE QSFP28 Thumbscrew Type |
| Transceiver | NMC-TEL100S-00A1 | 100Gbps SR 850nm 70m/100m |
| Transceiver | NMC-TEL100L-00A1 | 100Gbps LR 1310nm 10km |
NMC-6003L
