| NVIDIA® Jetson Orin™ NX | ||
|
处理器系统 |
CPU | 16GB: 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU |
| GPU | 1024-core NVIDIA Ampere GPU with 32 Tensor Cores | |
| 内存 | 16GB LPDDR5 | |
| 闪存 | - | |
|
I/O |
以太网 | 6 x 10/100/1000 Mbps (4 x PoE support, IEEE 802.3af) in M12 X-coded, 8-pin female connector |
| 显示 | HDMI (Max. resolution 3840 x 2160 @ 60Hz) | |
| USB | External: 2 x USB 3.0 | |
| CAN Bus | 2 x CAN bus | |
| OTG USB | 1 x Micro USB | |
|
扩展 |
Mini PCIe | 2 x mPCIe (signal: PCIe + USB) |
| SIM | 2 x Nano SIM slot (M.2 3052 & Mini PCIe2 slot) | |
| M.2 1 x M.2 3052 (B-Key, signal: PCIe + USB) | ||
| 存储 | M.2 1 x M.2 2280 M-Key (NVMe, PCIe x1) | |
| 电源 | 模式 | M16, 6-pin male |
| 输入功率 | 12/24VDC (12-6A) with ignition *Note1 | |
|
工作环境 |
工作温度 | -20 ~ 60 °C with 0.7 m/s airflow (Max-N ARM mode) |
| 工作湿度 | 95% @ 40 °C (非冷凝) | |
| 振动 | 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis | |
| 冲击 | 10G/11ms | |
|
物理特性 |
尺寸（宽× 深× 高） | 275 x 220 x 80 mm (10.8" x 8.7" x 3.2") |
| 重量 | 4.5 kg | |
| 安装 | Desktop | |
| BSP | Jetpack | Above 5.1 |
| 认证 | CB/UL/CE/FCC/CCC (No RED certification) | |
注1：默认设置为12V DC输入。若电源为24V，请打开机箱并将SW1 DIP开关调至01位置以适配24V DC输入。
| 料号 | NVIDIA 模块 | 内存 | 已安装的 JetPack 版本 | NVMe** | 超级模式支持 |
| MIC-715-OX4A1 | Orin NX | 16GB | JP6.0 | 128GB pre installed | NO |
| MIC-715-OX4A2 | Orin NX | 16GB | NA | NA | NO |
| 料号 | 描述 | 数量 |
| MIC-715-OX4A1 | Ruggedized Al System based on Orin NX | 1 |
| 1700023619-01 | Micro USB Cable | 1 |
| 1700032301-01 | 6-pin M12 power cable | 1 |
| 1930005673-11 | M2 Screws | 2 |
| 1930008089 | Mini PCle Screws | 2 |
| 料号 | 描述 |
| XSK320-LRS-150-12 | Open Frame, A/D 100-240V 150W 12V |
| 类别 | 料号 | 描述 | 数量 |
| Cable | 1700025503-01 | M Series Waterproof Cable 8P/RJ45-8P8C 100cm (M12 to RJ-45) | 1 |
| 1700022250-21 | Type-A Waterproof Cable 5P(F) 200cm (CAN cable) | 1 | |
| Thermal Kit | 98R27150000 | M2 3052 / Mini PCIe module thermal kit | 1 |
|
Wifi |
EWM-W173H01E | Wi-Fi 6+BT 5.0 Module 2.4/5GHz Mini PCIe | 1 |
| 1751000626-01 | RF Cable SMA/F-R MHF1/113 BLK L250mm | 2 | |
| 1751000460-01 | Dipole Ant. WiFi 6E SMA/M-R BLK L111.7mm IP54 (Wi-Fi) | 2 | |
| 9656EWMG00E | Half-size miniPCIe to miniPCIe bracket set | 1 | |
|
5G |
AIW-356-DQ | 5G Sub6+GNSS M.2 3052 Key B (by region) | 1 |
| 1751000624-01 | Cable Ant. SMA/F MHF4L/113 BLK L250mm (5G) | 4 | |
| 1750009372-01 | Ant.SMA/M 90/180 5G BLK 167mm RG178 (5G) | 4 | |
|
SSD |
96FD80-P128-AH | APACER M.2 2280 NVME G4x4 128G -25°C ~ 85 °C | 1 |
| 96FD80-P256-AH | APACER M.2 2280 NVME G4x4 256G -25°C ~ 85 °C | 1 | |
| 96FD80-P1TB-TS1 | SSSTC M.2 2280 1TB NVME G4x4 SSD -25°C ~85°C | 1 | |
| SQF-C8MV2-128GDEDM | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 128G 3D TLC BiCS5 (-20~85°C) | 1 | |
| SQF-C8MV2-256GDEDM | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 256G 3D TLC BiCS5 (-20~85°C) | 1 | |
| SQF-C8MV2-512GDEDM | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 512G 3D TLC BiCS5 (-20~85°C) | 1 | |
| SQF-C8MV4-1TDEDM | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 1T 3D TLC BiCS5 (-20~85°C) | 1 | |
| SQF-C8MV4-2TDEDM | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 2T 3D TLC BiCS5 (-20~85°C) | 1 | |
| SQF-C8MV2-128GDEDE | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 128G 3D TLC BiCS5 (-40~85°C) | 1 | |
| SQF-C8MV2-256GDEDE | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 256G 3D TLC BiCS5 (-40~85°C) | 1 | |
| SQF-C8MV2-512GDEDE | SQF PCIe/NVMe Gen.3 M.2 2280 OPAL 720-D 512G 3D TLC BiCS5 (-40~85°C) | 1 |
