| NVIDIA® Jetson Orin™ Nano | ||
|
处理器系统 |
CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 |
| GPU | 8G: 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores 4G: 512-core NVIDIA Ampere architecture GPU with 16 Tensor Cores | |
| 内存 | 8GB: 8GB LPDDR5
4GB: 4GB LPDDR5 |
|
| 闪存 | - | |
|
I/O |
以太网 | 1 x 10/100/1000 Mbps |
| 显示 | HDMI (最大分辨率 3840×2160 @ 60Hz) | |
| USB | External: 2 x USB 3.2 Gen 2, 1 x USB 2.0 Internal: 1 x USB 2.0 (by pin header) | |
| OTG USB | 1 x Micro USB | |
|
扩展 |
Mini PCIe | 1 x mPCIe (Signal: PCIe + USB 2.0) |
| M.2 1 x M.2 3052 (B-Key, Signal: USB) | ||
| GMSL (可选) | 2-ch GMSL2.0 with FAKRA connectors | |
| SIM | 2 x Nano SIM slots | |
| 存储 | M.2 1 x M.2 2280 (M-Key, NVMe, Signal: PCIe x4) | |
| SD Card | 1 x Micro SD | |
| 风扇 | 尺寸 | 60 x 60 x 13 mm (2.36" x 2.36" x 0.51") |
| RPM | 5400 RPM | |
| 电源 | 模式 | Terminal block, 2-pin, AT |
| 输入电压 | 9~36 VDC | |
|
物理特性 |
尺寸 (宽 x 深 x 高) | 125 x 125 x 51 mm (5.1" x 5.1" x 1.8") |
| 重量 | 0.8 kg (1.76 lb) | |
| 安装 | Desktop | |
| BSP | Jetpack | Above 5.1 |
| 料号 | NVIDIA 模块 | NVIDIA模块内存 | 已安装的 JetPack 版本 | NVMe | 超级模式支持 |
| MIC-711D-ON3A1 (EOL) | Orin Nano | 8GB | JP5.1.2 | 128GB pre installed | Yes (needs to update to JetPack 6.2) |
| MIC-711D-ON2A1 (EOL) | Orin Nano | 4GB | JP5.1.2 | 128GB pre installed | Yes (needs to update to JetPack 6.2) |
| MIC-711D-ON3A2 | Orin Nano | 8GB | JP6.2 | 128GB pre installed | Yes (default) |
| MIC-711D-ON2A2 | Orin Nano | 4GB | JP6.2 | 128GB pre installed | Yes (default) |
| 料号 | 描述 | 数量 |
| MIC-711D-ON | AI 开发套件 | 1 |
| 1652002202 | Power connector — 2-pin | 1 |
| 料号 | 描述 | 数量 |
| 1700023619-01 | Micro USB cable for system recovery | 1 |
| 1930005673-11 | M.2 screw | 2 |
| 1930008089 | Mini PCIe screw | 2 |
| 类别 | 料号 | 描述 | 数量 |
| 适配器 | 96PSA-A65W19P2-1 | Power Adapter 100-240V 65W 19V | 1 |
|
电源线 |
1700001524 | Power Cord UL 3P 10A 125V 183 cm (US) | 1 |
| 170203183C | Power Cord EU 3P 2.5A 250V 183 cm (EU) | 1 | |
| 170203180A | Power Cord BSI 3P 2.5A 250V 183 cm (UK) | 1 | |
| 1702031836 | Power Cord SAA 3P 10A 250V 183 cm (AU) | 1 | |
| 1700008921 | Power Cord PSE 3P 7A 125V 183 cm (Japan) | 1 | |
| 1700019146 | Power Cord CCC 3P 2.5A 250V 183 cm (China) | 1 | |
| GMSL | MIC-FG-4G2C1 | 4ch GMSL Video Capture Card | 1 |
| 1751000805-01 | RF Cable FAKRA-Z/F FAKRA-Z/F KS302 BLK L15M | by camera quantity | |
|
Wifi |
EWM-W173H01E | Wi-Fi 6+BT 5.0 Module 2.4/5GHz Mini PCIe | 1 |
| 1751000626-01 | RF Cable SMA/F-R MHF1/113 BLK L250mm | 2 | |
| 1751000460-01 | Dipole Ant. WiFi 6E SMA/M-R BLK L111.7mm IP54 (Wi-Fi) | 2 | |
|
5G |
AIW-356-DQ | 5G Sub6+GNSS M.2 3052 Key B (by region) | 1 |
| 1751000624-01 | Cable Ant. SMA/F MHF4L/113 BLK L250mm (5G) | 4 | |
| 1750009372-01 | Ant.SMA/M 90/180 5G BLK 167mm RG178 (5G) | 4 | |
| OOB | 98RV710AL00 | Allxon OOB module (By adding Expansion kit) | 1 |
