MIC-332AO

研华MIC-332AO 是一款3U CPCI-Serial AI 边缘计算卡,嵌入NVIDIA® Jetson AGX Orin™ 算力高达275 TOPS,丰富的I/O接口（PCIe3.0 x8、GbE和10GbE）连接到背板上。

3U CPCI-S 边缘 AI 计算卡
嵌入NVIDIA® Jetson AGX Orin™ 算力高达275 TOPS
支持GbE、2 x USB 3.2 Gen 2（10 Gbit/s）、1 x HDMI on 4HP
支持1 x DB9，1 x micro USB在8HP I/O-1上
支持4 x GMSL2.0，1 x micro USB在8HP I/O-2上
主板上的 PCIe 3.0 x4 M.2 M key存储
丰富的I/O接口（PCIe3.0 x8、GbE和10GbE）连接到背板上

产品型录PDF

如需帮助,请联系我们

免费电话：400-880-8951

公司邮箱：advavee@outlook.com
咨询客服：一站式采购

批量采购定制咨询，请发送您的需求，我们将立即回复。

产品资讯

Specifications

	NVIDIA® Jetson AGX Orin™
	MIC-332-AO32 MIC-332-AO64
Processor	NVIDIA Jetson Series	AGX Orin 32G AGX Orin 64G
	CPU	8-core NVIDIA Arm® Cortex A78AE v8.2 12-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU, 2 MB L2 + 4 MB L3 64-bit CPU, 3 MB L2 + 6 MB L3
	GPU	1792-core NVIDIA Ampere GPU with 56 Tensor 2048-core NVIDIA Ampere GPU with 64 Tensor Cores, maximum operating frequency: 930 MHz Cores, Maximum Operating Frequency: 1.3 GHz
	Al Performance Reference	Up to 200 TOPS Up to 275 TOPS
	Memory	32 GB 256-bit LPDDR5 DRAM 64 GB 256-bit LPDDR5 DRAM
Graphics	Chipset	Integrated on Jetson module
	I/O Connector	HDMI 2.0
	Resolution	3840 x 2160 @60 Hz
Ethernet	Interface	10/100/1000 BASE-T, 2.5 G BASE-T, 10 G BASE-T
	Chipset	Marvell GbE Ethernet PHY transceiver_88E1512, routing to backplane GbE signal Marvell 10GbE Ethernet PHY transceiver_AQR113C, routing to backplane 10GbE signal Intel i226 Ethernet controller, to front I/O ports
	I/O Connector	2 x RJ45 or M12 connector to front I/O, up to 2.5 Gbps
Storage	Mode	eMMC, PCIe 3.0
Storage	Channels	1 x 64GB eMMC 5.1 integrated into Jetson module 1 x M.2 2242 (M-Key, NVMe, Signal: PCIe x4)
Front I/O	USB	2 x type A USB 3.2 Gen2 @ 10 Gbps
	LAN	2 x RJ45 or M12 X-code GbE / 2.5 GbE
	Display	1 x HDMI 2.0 port
	Micro-USB	1 x Micro-USB
	COM/GMSL	1 x DB9 (RS232, 4 line) or 4 GMSL 2.0 port
	Front Panel LEDs	1 x blue/orange hot swap/HDD cable, 1 x green PWR cable, 1 x green primary/secondary cable, front LAN activity/speed (2.5 G / green, GbE / yellow, others: off)
	Buttons	System reset button x1, recovery mode button x1 for BSP programming

Specifications (Cont.)

To CPCI-S Backplane Resources	P1	1 x I2C
	P2	1 x PCIe 3.0 x8, 4 x GPIO
	P5	2 x PCIe clock, 2 x PCIe clock REQ
	P6	1 x GbE, 1 x 10 GbE
Operating System	Compatibility	Linux Kernel 5.10, Ubuntu 20.04, Jetpack 5.1.2
Physical	Dimensions & Weight	160 mm x 100 mm 8HP
Environment	Temperature	Operating (depending on forced airflow) Non-operating
	-25°C ~ 70°C (-13°F ~ 158°F) -40°C ~ 85°C (-40°F ~ 185°F)
	Humidity	95% @ 40°C, non-condensing 95% @ 60°C, non-condensing
	Vibration	2Grms, random (5 Hz ~ 500 Hz)
	Shock	10 G, 11ms, each axis three times during operation mode
Regulatory	Certification	CE, FCC, UKCA, RoHS
Regulatory	Design to Meet	EN50155, EN50121-4
Compliance	Standards	PICMG® CompactPCI® Serial

Ordering Information

System board	Front Panel						Onboard Features		Others
System board	2.5G LAN (M12 X-code)	HDMI	USB3.2 (TypeA)	COM (DB9)	GMSL port	Micro USB	NVMe (M.2 M key)	Jetson module	Width Height
MIC-332-AOC32	2	1	2	1	NA	1	1	32GB	8HP
MIC-332-AOC64	2	1	2	1	NA	1	1	64GB	8HP
MIC-332-AOG32	2	1	2	NA	4	1	1	32GB	8HP

Note: Dual M12 X-code connector can be replaced by RJ45 port per request

Related Products

Peripheral board	Description
MIC-300A series	3U CPCI-Serial 84HP/44HP width, 3U/4U height chassis, with 8 slots backplane & mini fan
MIC-3954D series	3U CPCI-Serial quad Mini-PCIe carrier board
MIC-3954E series	3U CPCI-Serial quad M.2 (1 x E-Key, 3 x B-Key) carrier board for wifi/LTE/GPS module
MIC-3954F series	3U CPCI-Serial quad port USB3.0 typeA board
MIC-3810 series	3U CPCI-Serial PCIe PCIe x8 / x16 carrier board
MIC-3860 series	3U CPCI-Serial quad RJ45 or 4 M12 2.5 Gbps LAN board with PoE support option
MIC-3861 series	3U CPCI-Serial 10GbE dual SFP+ fiber & dual copper RJ45 or M12 ports ethernet card
MIC-3812 series	3U CPCI-Serial MXM carrier board for type A/B/B+ module
MIC-3821 series	3U CPCI-Serial quad M.2 M-Key NvME carrier board
MIC-3840 series	3U CPCI-Serial DB62 to 8*DB9 isolated RS323/422/485 serial board
MIC-3890	3U CPCI-Serial DC-DC power module, 110 V input / 12 V & 5 V output, 250 W
XMIC330-HAC300S	3U CPCI-Serial AC-DC power module, 12 V & 5 V output, 300 W
