研华MIC-3329 是一款基于Intel® Atom™ 四核处理器的3U CompactPCI卡,支持DDR3L-1333 ECC 板载内存, 容量可支持 4GB,采用优化散热设计, 无风扇应用，符合 EN50121-4 和 EN50155 标准, 适于铁路应用
如需帮助,请联系我们
免费电话：400-880-8951
公司邮箱：advavee@outlook.com
咨询客服：一站式采购
批量采购定制咨询，请发送您的需求，我们将立即回复。
Specifications
|
Processor System |
CPU | Intel® Atom™ Processor E3826/E3827/E3845 |
| Max Speed | Up to 2MB L2 Cache, 1.91 GHz | |
| BIOS | 2 x AMI 8 MByte SPI flash | |
| Memory | Technology | Single Channel DDR3L 1066/1333 MHz with ECC |
| Max. Capacity | Up to 4GB on board | |
|
Compact PCI Interface |
J1 Connectors | 32bit/33MHz PCI local bus |
| J2 Connector | RTM | |
| Mode | System Master/Drone (Stand alone) | |
|
Ethernet |
Controller | Intel® WGI210 SLJXR Gigabit Ethernet Controller |
| Interface | PCIe 1.0 x 1, 10/100/1000 Base TX Ethernet | |
| I/O Connector | 2 x RJ45 to 4HP front (Switchable with RIO 4HP); 2xM12 X-Code, 2xM12 D-Code on 8HP front | |
|
Graphics |
Chipset | Integrated in processor |
| I/O Connector | 1 x VGA to 4HP front (Switchable with RIO 4HP) | |
| Resolution | 1 x VGA 2560 x 1600, 60Hz | |
|
Storage |
Mode | SATA-II |
|
Channels |
Option 1: 1 x SATA connector and 1x Cfast connector on 8HP
Option 2: 1 x SATA connector on 8HP and 1 x Cfast socket on RTM (Switchable with NAND flash, upon request) Option 3: 2 x M.2 SATA on 8HP |
|
|
Front I/O |
USB | 1 x US2.0 type A, 1 x USB3.0 type A |
| VGA | 1 x VGA (Switchable with RIO) | |
| LAN | 2 x 10/100/1000Mbps on RJ45 (Switchable with RIO) | |
| Front Panel LEDs | x 1 blue/yellow for Hot Swap/HDD, x 1 green for Power, and x 1 green for Master/Drone mode | |
|
8HP (XTM) |
Option 1: 2 x DB9 COM; 1 x PS/2; 1 x Audio Line in/out Option 2: 1 x DB9 COM; 2 x M12 X-coded GbE
Option 3: 2 x M12 X-code, 2 x M12 D-code |
|
| Buttons | System reset button | |
|
To RTM |
USB | 2 x US2.0 type A, |
| VGA | 1 x VGA (Switchable with front) | |
| LAN | 2 x 10/100/1000Mbps on RJ45 (Switchable with front) | |
| 8HP (XTM) | 2 x COM port on DB9 (RS232/422/485) | |
| BIOS | Boot Options | SATA, USB, network (PXE) |
Specifications (Cont.)
| Watchdog Timer | Output | Local reset | |
| Interval | Programmable 1s ~ 255s | ||
| Operating System | Compatibility | Windows7, Windows 10, Linux, CentOS6.6, VxWorks 6.9 & 7.0 | |
| Physical | Dimension & Weight | 3U/ 4HP&8HP: 100mm x 160 mm | |
|
Environment |
Operating | Non-operating | |
| Temperature | -40 ~ 70 °C (-40 ~ 158 °F) Fanless | -40 ~ 85 °C (-40 ~ 185 °F) | |
| Humidity | 95 % @ 40 °C, non-condensing | 95 % @ 60 °C, non-condensing | |
| Vibration | 2Grms (X,Y,Z 1H/axis, w/o HDD) | 2G | |
| Shock | 30 G, 11ms, each axis three times | ||
| Regulatory | Conformance | FCC Class A, CE, RoHS EN50121-4, EN50155 | |
| Compliance | Standards | PICMG2.0 R3.0, PICMG2.1 R2.0 | |
Supported CPU Configurations
| Intel® CPU Model Number | # Cores | Freq. | Cache | Memory Types | CPU TDP |
| Intel® Atom™ Processor E3845 | 4 | 1.91GHz | 2 MB L2 Cache | DDR3L-1333 | 10W |
Ordering Information
| Front/Rear Panel | On Board Features | ||||||||||
| 4HP | 8HP XTM | ||||||||||
| RJ45 LAN (1) | USB2.0 | USB3.0 | VGA (2) | CPU | M12 LAN | COM | Audio | PS/2 | SATA Conn. | Cfast Socket | |
| P/N List | Front Board | ||||||||||
| MIC-3329C1-D2E | 2 | 1 | 1 | 1 | E3845 | 2 | 1 | N/A | N/A | 1 | 1 |
| MIC-3329C2-D2E | 2 | 1 | 1 | 1 | E3845 | 4 (3) | N/A | N/A | N/A | 2 | N/A |
| MIC-3329C3-D2E | 2 | 1 | 1 | 1 | E3845 | N/A | 2 | 1 | 1 | 1 | N/A |
| P/N List | RIO Board | ||||||||||
| MIC-3329R1-D1E | 2 | 2 | N/A | 1 | N/A | 2 | N/A | N/A | N/A | N/A | |
Notes:
*(1)(2) are switchable between front and rear boards.*On board NAND flash is requested by customer. (3) 4*M12: 2*M12 X-Code,2*M12 D-Code
(4)MIC-3329C1-D1E replace modelis MIC-3329C3-D2E
Related Products
| Peripheral board | Description |
| MIC-3955 | 3U CPCI 4 or 8 ports RS232/422/485 communication card, with RIO support |
| MIC-3958 | 3U CPCI 4/2 port RJ45 or M12 X-code Gigabit Ethernet Card, with RIO support |
| MIC-3022 | 4U enclosure for 3U cards, with RIO support |
| MIC-3023 | 3U enclosure for 3U cards, with RIO support |
