研华HPC-7140 是一款1U 机架式服务器机箱，适用于 MicroATX/ATX 服务器主板，支持4个3.5″热插拔盘位，1个全长/半长PCI-E x16扩展插槽，易于更换和防振风扇设计。
如需帮助,请联系我们
免费电话：400-880-8951
公司邮箱：advavee@outlook.com
咨询客服：一站式采购
批量采购定制咨询，请发送您的需求，我们将立即回复。
Specifications
| Form Factor Support | MicroATX/ATX | ||
| Expansion Slots | 1 (Full Height / Half Length) | ||
|
Drive Bay |
Slim ODD Bay | 1 (ODD should be purchased separately) | |
| 5.25" (front-accessible) | - | ||
| 3.5" (hot-swappable) | 4 x SATAlll | ||
| 3.5" (internal) | - | ||
| 2.5" (hot-swappable) | Optional | ||
| 2.5" (internal) | - | ||
| Cooling | Chassis Fan | 4 (4cm / 23CFM) | |
| Air Filter | - | ||
| System Monitoring | Chassis intrusion switch | Yes | |
| Front I/O Interface | USB 2.0 | 2 | |
| COM Ports | 1 | ||
|
Miscellaneous |
LED Indicators | System : Power, LAN1, LAN2, HDD, System Information HDD Tray: HDD Power and Activity LED | |
| Rear Panel | - | ||
|
Environment |
Operating | Non-Operating | |
| Temperature | 0 ~ 35 °C (32 ~ 95 °F) | -40 ~ 70 °C (-40 ~ 158 °F) | |
| Humidity | 10 ~ 85% @ 40 °C non-condensing | 10 ~ 95% @ 40 °C, non-condensing | |
| Vibration (5-500 Hz) | 0.25Grms | 0.5G | |
| Physical Characteristics | Dimensions (W x H x D) | 437 x 43 x 504 mm (17.2" x 1.7" x 19.85") | |
Ordering Information
| Part Number | Description |
| HPC-7140-00A1E | HPC-7140 1U 4 bays server chassis (w/o single power supply) |
Packing List
| Items | Quantity |
| Hot-Swap 3.5" HDD tray with SATA cable (Pre-install) | 4 |
| Accessory Box | 1 |
Power Supply Options
| Part Number | 80 Plus Grade | Wattage | Type | Input |
| PS8-350FATX-GB | Gold | 350W | Single | AC 100 ~ 240V
(full range) |
| PS8-500FATX-GB | Gold | 500W | Single | AC 100 ~ 240V
(full range) |
Optional Accessories
| Part Number | Description |
| 19Z0001156T000 | 1U IO Shield for ASMB-585/785 |
| 1960088060T001 | 1U IO Shield for ASMB-586/786 |
| 1960082347T000 | 1U IO Shield for ASMB-815 |
| 1960082348T000 | 1U IO Shield for ASMB-825 |
| 1703040150 | Type Y of Peripheral B4P Power Connector |
| 96CB-SATAPOWER-6P2 | SATA POWER ADAPTER 6PIN TO BIG 4 PIN(G) for
Slim ODD |
| AIMB-RF10F-01A1E | 1U PCIe x16 to PCIe x16 Riser Card |
| 1960094951N000 | 2.5" HDD Bracket for Swappable HDD Tray |
| 9680016685 | 25.6" - 33" Rail Kit for HPC-7140 |
