| Form Factor | Tiny box | |||
|
Processor System |
Processor | Intel Atom® x7203C | Intel Atom® x7405C | Intel Atom® x7809C |
| Core Count | 2 | 4 | 8 | |
| Base Frequency | 2.0 GHz | 2.2 GHz | 2.4 GHz | |
| BIOS | AMI UEFI | |||
| Virtualization | Intel® VT-x, VT-d | |||
|
Memory |
Technology | DDR4 | ||
| Max. Capacity | 32 GB | |||
| Socket | 1 x 260-pin SO-DIMM | |||
| ECC Support | In-Band ECC | |||
|
Networking |
Controller | 4 x Intel i226-V
Default not installed: 1x DP83867 PHY, is optional by project support |
||
| 1GbE | Default not installed: 1 x 1GbE RJ45 is optional by project support | |||
| 2.5GbE | 4 x 2.5GbE RJ45 | |||
|
Expansion Slot |
M.2 (Except SSD) |
1 x B-key 3052/3042 for 5G or 4G/LTE module 1 x B-key 3042 for 4G/LTE module
1 x E-key for WiFi module Use condition is as one of scenarios: 1 x M.2 5G module, or 2 x M.2 4G LTE module, or 1 x M.2 Wi-Fi module, and 1x M.2 4G LTE module |
1 x M.2 5G module, and 1x M.2 4G LTE module; or 1 x M.2 5G module, and 1x M.2 Wi-Fi module; or 1 x M.2 4G LTE module, and 1x M.2 Wi-Fi module; or 2 x M.2 4G LTE module |
|
| SIM Socket | 2 x Dual Nano SIM slots for each LTE/5G module | |||
| Storage | M.2 (SSD) | 1 x M.2 M-key slot for 2242 SATA SSD (SATA 3.0) | ||
| eMMC | Default not installed: Up to 128 GB eMMC, is optional by project support | |||
|
I/O |
Console | 1 x RJ45 type console | ||
| USB | 2 x USB 3.1 | |||
|
LED Indicator |
1 x HDD LED
1 x LTE/5G LED 1 x 4G/LTE LED 1 x Wi-Fi LED 2 x Software-defined LED |
|||
| Video | Default not supported: 1 x HDMI port, is optional by project support | |||
| Button | 1 x Power button with LED indication 1 x Software-defined button | |||
| TPM | TPM 2.0 module (Optional) | |||
|
Power Supply |
Power Type | External power adapter | ||
| Watts | 60 W | |||
| Input | 100-240 V ~ 1.5A 50-60 Hz | |||
| Connector | AC 3pin connector | |||
|
Environment |
Operating Temperature | 0 ~ 40 °C (32~104 °F) | |
| Non-operating Temperature | -40 ~ 70 °C (-40 ~ 158 °F), 60 °C@95% non-condensing humidity | ||
| Vibration Resistance (Operation) | 5-500 Hz, 1.0 Grms, 3 axes, 1 hr/per axis | ||
| Shock Protection (Operation) | 10 G, 11 ms | ||
| Cooling | Fanless | 2 x System fans with smart fan feature | |
|
Mechanical |
Construction | SGCC | |
| Dimensions (W x H x D) | 159 x 29 x 139 mm (6.2" x 1.1" x 5.5") | 190 x 43.7 x 139 mm (7.4" x 1.7" x 5.5") | |
| Weight | 0.7 kg (1.55 lb) | 0.9 kg (1.98 lb) | |
| OS Support | Linux OS
Only UEFI FW and UEFI aware Linux OS |
||
|
Advantech S/W Pakhages |
1. Server iManager (Linux base)
-Server Monitoring -Summary -network device identifier (apdi) 2. Quick Start Linux Image |
||
| Certification | EMC/Safety | CE, FCC, CB, UL, CCC | |
| Part Number | Processor | SO-DIMM
DDR4 slot |
USB 3.1 | Console Port | LAN Port 2.5G RJ45 | M.2 2242
SSD slot |
M.2 3042/3052
LTE/5G/ slot |
M.2 3042
4G/LTE slot |
Nano SIM slot | M.2 2230
WiFi slot |
System fan | eMMC* | PSU |
| FWA-T014-2CA1S | x7203C | 1 | 2 | 1 | 4 | 1 | 1 | 1 | 2 | 1 | Fan-less | Optional | 60W |
| FWA-T014-4CA1S | x7405C | 1 | 2 | 1 | 4 | 1 | 1 | 1 | 2 | 1 | Fan-less | Optional | 60W |
| FWA-T014F-8CA1S | x7809C | 1 | 2 | 1 | 4 | 1 | 1 | 1 | 2 | 1 | 2 | Optional | 60W |
* eMMC is optional by project support
| Part Number | Description | Quantity |
| 96PSA-A60W12W7-3 | Power AC adapter 60W | 1 |
| 1990042021N000 | Thermal pad for M.2 SSD module | 1 |
| 1990042018N000 | Thermal pad for SO-DIMM memory module | 1 |
| 1910003081-01 | Post for TPM module | 1 |
| 1930001074 | M3 Screws for M.2 SSD, TPM module…. | 4 |
| Part Number | Description |
| 1702002600 | Power cord 3P 180 cm, USA |
| 1702002605 | Power cord 3P 180 cm, Europe |
| 1702031801 | Power cord 3P 180 cm, UK |
| 1700000237 | Power cord 3P 180 cm, JP |
| 1700009652 | Power cord 3P 180 cm, China |
| PCA-TPMSPI-00A1 | TPM 2.0 Module, SPI |
