ASMB-789

ATX 服务器主板搭载Intel® Core™ Ultra 9/7/5, DDR5,与第五代 PCIe 总线，面向工作站、通用服务器及多任务运算场景。

搭载 LGA 1851 插槽、W880 芯片组，支持Intel® Core™ Ultra 9/7/5 系列处理器，释放新一代强劲算力。
Supports up to 192 GB of high-speed DDR5 ECC/Non-ECC UDIMM memory at up to 5600 MT/s.
最高支持 192GB 高速 DDR5 内存，兼容 ECC / 非 ECC UDIMM，内存速率可达 5600MT/s。
搭载 DP、VGA、HDMI 2.0 三类视频输出接口，可驱动三路独立显示输出，搭建高性能多屏视觉作业平台。
配备 4 组 SATA 3 接口用于传统存储设备，7 个 USB 3.2 高速接口可外接各类高速外设。
板载 1 个 PCIe x4 通道 M.2 2280 插槽，支持高速 NVMe 固态硬盘，有效缩短开机加载时间、提升应用程序运行效率。
整机采用机架式优化结构，风道流通顺畅，在服务器机房环境下强化散热能力，提升整机运行稳定性。
设备可在 0～60 摄氏度环境温度区间稳定运行，适配各类工业应用场景。

ASMB-789 _ 技术规格

分类： 5G 和边缘运算服务器, 云、网络和服务器, 工作站主板, 服务器主板标签： ASMB-789

如需帮助,请联系我们

免费电话：400- 880- 8951

邮箱：advavee@outlook.com
咨询客服：一站式采购

批量采购定制咨询，请发送您的需求，我们将立即回复。

产品资讯

Specifications

Form Factor	ATX form factor
Processor System	Socket	Intel® LGA 1851
Processor System	CPU type	Intel® Core™ Ultra 9/7/5 processors (TDP up to 125W)
Core Logic	Chipset	Intel® W880 chipset
Memory	Total slots	4 x (Dual Channel)
	Max. capacity	192GB
	Memory type	5600/4800/4400 MT/s UDIMM(288-pin), 6400 MT/s CUDIMM(288-pin)
	Memory size	8 GB, 16 GB, 24 GB, 32 GB, 48 GB , 64 GB (CUDIMM)
Expansion Slots	Total PCI/PCIe slots	7
	Slot location 1	PCIex x4 slot (PCIe Gen4 x2 link) for G2 version; M.2 2280 (PCIe Gen4 x2 link) for G4 version
	Slot location 2	PCIe x 4 slot (Gen 4 x 4 link)
	Slot location 3	PCIe x4 slot (Gen 4 x4 link)
	Slot location 4	PCIe x8 slot (Gen5 x8 link)
	Slot location 5	PCIe x 4 slot (Gen 4 x 4 link)
	Slot location 6	PCIe x 4 slot (Gen 4 x 4 link)
	Slot location 7	PCIe x16 slot (Gen5 x8 or x16 link)
Graphics	Controller	Intel® HD Graphics
Graphics	VRAM	1 GB maximum shared memory with 2 GB and above system memory installed
Storage	SATA controller	Intel® W880: 4 SATA3 6 Gb/s ports with Intel Rapid Storage Technology support (for Windows only) (Supports software RAID 0, 1, 10, & 5)
Storage	SAS controller	-
Networking	Interface	10/100/1000 Mbps
	Controller	GbE LAN1: Intel® I219; GbE LAN2: Intel® I210-AT; GbE LAN 3~4: Intel® I226
	Connector	RJ-45 x 2 for G2 version; RJ-45 x 4 for G4 version
Onboard I/O Connector	Printer Port connector	-
	PSU connector	24-pin SSI power connector + 8-pin SSI 12V power connector
	USB connector	9 (1 x USB 3.2 Gen 1 (2 ports), 2 x USB2.0 (4 port), 1 x USB Gen2 Type E, 1 x USB3.2 Gen1 Type-A, 1 x USB2.0 Type-A)
	M.2 connector	1 x M.2 2280 M-Key (PCIe Gen4 x 4 link) 1 x M.2 2280 M-Key (PCIe Gen4 x 2 link)- For G4 version only
	Fan header	5 x (4-pin)
	SMBus	1
	Chassis intrusion	1
	Front LAN LED	2
	Serial port header	5 (2 x RS-232 dual-port (4 ports), 1 x RS-232 single-port)
	Audio connector	1 x (ALC 888S)
	PS/2 KB/Mouse	-
Rear I/O Connector	External serial port	1
	External USB port	4 x (USB 3.2 Gen 2)
	VGA port	1 x (Resolution up to 1920 x 1200 @ 60 Hz)
	HDMI port	1 x (Resolution up to 4096 x 2160 @ 60 Hz)
	Display Port	1 x (Resolution up DP* with DSC to 8K60 Hz 36bpp)
	RJ-45	2 for G2 sku; 4 for G4 sku
	Audio connector	2 x (Mic-in, Line-out)
	PS/2 KB/Mouse	-
Watchdog Timer	Output	System reset
Watchdog Timer	Interval	Programmable 1 ~ 255 sec
Power Requirement	Power On	3.3 V 5 V 12 V 12 V_8P 5 VSB
Power Requirement	(Ultra9 285 3.7GHz DDR5 5600 32 GB x 4)	2.02 A 2.54 A 0.39 A 0.69 A 0.09 A
Environment	Operating Non-operating
	Temperature	0 ~ 60 °C, depends on CPU speed and cooler solution -40 ~ 85 °C
	Humidity	40 °C @ 95% RH Non-condensing 60 °C @ 95% RH Non-condensing
Physical Characteristics	Dimensions	304.8 x 244 mm (12 x 9.6 in)

5600/6400 MT/s can only be supported with 1 DIMM per channel configuration (2 DIMMs in total).

Ordering Information

Part Number	Chipset	Memory	Display	LAN	SATAIII	IPMI
ASMB-789G2-00A1	W880	DDR5 Non-ECC/ECC UDIMM	VGA + DP + HDMI	2	4	-
ASMB-789G4-00A1	W880	DDR5 Non-ECC/ECC UDIMM	VGA + DP + HDMI	4	4	Y
ASMB-789G4-00A1U	W880	DDR5 Non-ECC/ECC UDIMM	VGA + DP + HDMI	4	4	Y

Packing List

Part Number	Description	Quantity
2042078900	Startup manual	x 1
1700003194	SATA data cables	x 2
1700022749-11	SATA power cables	x 2
1960119032T001	I/O shield (for 2U chassis or higher)	x 1
1930005673-11	Screw for M.2 device	x 1

Optional Accessories

Part Number	Description
1700029038-01	BMC VGA cable with bracket (35 cm / 13.7 in, for G4 SKU)

Note: If you need BMC KVM function, please select this cable.

Part Number	Description
1970005958N001	LGA 1700 CPU Cooler for 3U/4U Tower Cooler (CPU 230W at ambient 30°C)
1970005436T001	LGA 1700 CPU cooler for 2U/4U chassis (CPU 125W)
1970005349T000	LGA 1700 CPU cooler for 2U/4U chassis (CPU under 65W)
1700002204	Dual-port USB 2.0 cable (27 cm / 10.6 in) with bracket
1700008461	Four-port USB 2.0 cable (30.5 cm / 12 in) with bracket
1700028292-01	Dual-port USB 3.0 cable (30 cm/ 11.8 in) with bracket
1701090401	Single port RS-232 COM cable (40 cm / 15.7 in) with bracket
1700026254-01	Dual-port RS-232 COM cable (45 cm/ 17.7 in) with bracket
1700036239-01	M cable USB-E 20P(M)/USB-C 24P(F) 65cm W/BKT 3.2
PCA-TPMSPI-00A1	TPM 2.0 Module by SPI
