研华MIC-3396 是一款基于第4代Intel®Core™ i3/i5/i7处理器6U CompactPCI刀片计算机，支持五个千兆以太网端口，包括两个PICMG 2.16端口
需要帮助吗？请联系我们。
免费电话：400-880-8951
公司邮箱：advavee@outlook.com
咨询客服：一站式采购
批量采购定制咨询，请发送您的需求，我们将立即回复。
Specifications
|
Processor System |
CPU | 4th Generation Intel® Core™ i3/i5/i7 mobile processors up to 2.4 GHz (6MB LLC) |
| Platform Controller Hub | Intel® QM87 | |
| BIOS | Redundant AMI 8MByte SPI flash | |
|
CompactPCI Interface |
J1 Connector | 32-bit PCI local bus |
| J2 Connector | 64-bit PCI local bus | |
| J3 Connector | PICMG2.16 + RTM area, 1x PCIex8 | |
| J4~J5 Connectors | RTM area | |
| XMC/PMC Socket | PCIex8 | Gen3 (7GT/s) |
| PCI | 64-bit/66 MHz | |
|
Memory |
Technology | DDR3 1600 MHz, dual channel with low voltage and ECC support |
| Max. Capacity | Up to 16GB (max. 8GB on-board, max. 8GB SODIMM) | |
| Socket | SODIMM x1 | |
|
Graphics |
Controller | Intel® embedded graphic controller Iris (triple independent display) |
| VRAM | Dynamic | |
| Resolution | Up to 2048 x 1536, 64k colors at 75Hz | |
|
Ethernet |
Controller | 4 Intel® I210AT single-port Gigabit Ethernet controllers (on PCIe x1 channel) |
| Interface | 10/100/1000Base-TX Ethernet | |
| I/O Connector | PICMG 2.16 and RJ-45 x2 (RTM rear panel), RJ-45 x1 (front panel) | |
| Controller | 1 Intel® I217LM single-port Gigabit Ethernet controller | |
| Interface | 10/100/1000Base-TX Ethernet | |
| I/O Connector | RJ-45 (front panel) | |
|
Storage |
Onboard HDD/SSD | 1 2.5" (SATA-III) |
| Channels | Onboard SATA-III connector | |
| Onboard Flash | SATA-II | |
| Channels | 1 CFast socket (SATA-II)
1 on-board flash (SATA-II optional) |
|
| RTM | SATA-II | |
| Channels | 2 SATA-II connectors |
Specifications (Cont.)
|
Front I/O |
USB3.0 | 2 type A |
| USB2.0 | 1 type A | |
| VGA | 1 | |
| COM | 1 RS-232 on RJ-45 | |
| LAN | 2 10/100/1000 Mbps on RJ-45 | |
| Front Panel LEDs | x1 blue for Hot Swap, 1x yellow for HDD, x1 green for Master/Drone mode, x1 green BMC Heartbeat, and x1 green for Power | |
| Buttons | CPU reset button and BMC reset button | |
|
Rear I/O |
USB2.0 | 6 ports |
| COM | 2 ports | |
| LAN | 4 ports, one connectivity with front port | |
| SATA | 2 SATA-II | |
| PCIe | 1 PCIex8 Gen3 7GT/s | |
| Display | 1 DVI-I and 1 DVI-D | |
| Others | PS/2 for keyboard & mouse | |
| Watchdog Timer | Output | Local Rest and Interrupt |
| Interval | Programmable 1s ~ 255s | |
| Hardware Monitor | HWM | NCT7904 |
| BMC | Controller | LPC1768, IPMI v2.0 compliant |
| Operating System | Compatibility | Win7, Linux, VxWorks 6.x (on request) |
| Power Requirement | Configuration | 4HP |
| TDP | Maximum: up to 80W (quad core), 50W (dual core) or less, depending on CPU type | |
| Physical | Dimensions (W x D) | 233.35 x 160.0 mm |
|
Environment |
Operating Non-operating | |
| Temperature | 0 ~ 55 °C (32 ~ 122 °F) -40 ~ 85 °C (-40 ~ 185 °F) | |
| Humidity | 95 % @ 40 °C, non-condensing 95 % @ 60 °C, non-condensing | |
| Vibration (5-500 Hz) | 3.5Grms (without on-board 2.5" SATA HDD) | |
| Bump | 25G, 6ms | |
| Altitude | 15000ft, 55 °C above sea level 40000 ft, -40 °C above sea level | |
| Regulatory | Conformance | FCC Class A, CE, RoHS |
| Compliance | Standards | PICMG2.0 R3.0, PICMG2.1 R.0, PICMG2.9 R1.0, PICMG2.16 R1.0, |
Ordering Information
| System Board Model Number | Front Panel | Main On-board Features | |||||||||||
| VGA | USB3.0
(type A) |
USB2.0
(type A) |
Ethernet (RJ-45) | Console (RJ45) | CPU | Onboard Memory | Cfast Socket | Stroage Channel | SODIMM
Socket |
BMC | PCIex8 | XMC/ PMC | |
| MIC-3396HB-M8E | 1 | 2 | 1 | 2 | 1 | i5-4400E | 8GB | 1 | 1 SATA-III | 1 | No | Yes | Yes |
| MIC-3396HC-M8E | 1 | 2 | 1 | 2 | 1 | i7-4700EQ | 8GB | 1 | 1 SATA-III | 1 | Yes | Yes | Yes |
| MIC-3396HD-M8E | 1 | 2 | 1 | 2 | 1 | i7-4700EQ | 8GB | 1 | 1 SATA-III | 1 | Yes | No | No |
*Note: For i3 CPU, 4GB on-board memory and on-board flash available by request, please contact your local sales office.
CPU Configurations
| Intel® CPU Model Number | CPU
Architecture |
# Cores |
# Threads |
Freq. |
Cache |
CPU TDP |
ECC |
| i3-4100E | 22 nm | 2 | 4 | 2.4 GHz | 3 MB | 37W | Yes |
| i5-4400E | 22 nm | 2 | 4 | 2.7 GHz | 3 MB | 37W | Yes |
| i7-4700EQ | 22 nm | 4 | 8 | 2.4 GHz | 6 MB | 47W | Yes |
Related Products
| Model number | Configuration |
| RIO-3316-H1E | RTM Module with 4 LAN ports and USB 2.0 for MIC-3396 |
| MIC-3666-AE | Dual 10 Gigabit Ethernet XMC |
| MIC-3665-AE | CompactPCI PMC with dual copper (RJ-45) Gigabit Ethernet interfaces |
| MIC-3665-BE | CompactPCI PMC with dual fiber Gigabit Ethernet interfaces |
| MIC-3667-AE | Quad copper (RJ-45) Gigabit Ethernet XMC |
